| Print Area | 350mm * 15mm — 350mm * 20mm |
|---|---|
| Production Time | 10-19 days |
| RFID Chip(s) | MiFare Classic® 1K 4B — FM1108 4B — NTAG 213 — MiFare Ultralight® EV1 — MiFare® DESFire® — MiFare DUOX® — MiFare Plus® — iCode SLi — iCode SLiX — MiFare Ultralight® C — NTAG 203 — NTAG 216 — FM1108 7B — FM1132 4K — MiFare Classic® 1K 7B — HITAG® — TK4100 — EM4200 |
| Certificates |
|
| Specification | MiFare Classic® 1K 4B | FM1108 4B | NTAG 213 | MiFare Ultralight® EV1 | MiFare® DESFire® | MiFare DUOX® | MiFare Plus® | iCode SLi | iCode SLiX | MiFare Ultralight® C | NTAG 203 | NTAG 216 | FM1108 7B | FM1132 4K | MiFare Classic® 1K 7B | HITAG® | TK4100 | EM4200 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | NXP | Fudan | NXP | NXP | NXP | NXP | NXP | NXP | NXP | NXP | NXP | NXP | Fudan | Fudan | NXP | NXP | Fudan | EM Microelectronic |
| Frequency | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 13.56 MHz | 125 kHz | 125 kHz | 125 kHz |
| ISO/IEC Standard | ISO/IEC 14443A-3 (MIFARE Classic protocol) | ISO/IEC 14443A-3 (MIFARE Classic protocol) | ISO/IEC 14443A (Type A), NFC Forum Tag Type 2 | ISO/IEC 14443A (Type A) | ISO/IEC 14443A-4 (Type 4), ISO/IEC 7816-4 | ISO/IEC 14443A-4 (Type 4), ISO/IEC 7816-4 | ISO/IEC 14443A (Type A) | ISO/IEC 15693 (Vicinity) | ISO/IEC 15693 (Vicinity) | ISO/IEC 14443A (Type A) | ISO/IEC 14443A (Type A), NFC Forum Tag Type 2 | ISO/IEC 14443A (Type A), NFC Forum Tag Type 2 | ISO/IEC 14443A-3 (MIFARE Classic protocol) | ISO/IEC 14443A-3 (MIFARE Classic protocol) | ISO/IEC 14443A-3 (MIFARE Classic protocol) | ISO 11784/85, ISO 14223, ISO 18000-2 | ISO 11784/85, ISO/IEC 10536 | ISO 11784/85 |
| Max Range | 100.0 mm | 80.0 mm | 50.0 mm | 100.0 mm | 100.0 mm | 100.0 mm | 100.0 mm | 1500.0 mm | 1500.0 mm | 100.0 mm | 50.0 mm | 50.0 mm | 80.0 mm | 80.0 mm | 100.0 mm | 50.0 mm | 50.0 mm | 60.0 mm |
| Memory Capacity | 1024 bytes | 1024 bytes | 144 bytes | 48,128 bytes | 2048,4096,8192 bytes | 2048,4096,8192,16384 bytes | 2048,4096 bytes | 128 bytes | 128 bytes | 144,192 bytes | 144 bytes | 888 bytes | 1024 bytes | 4096 bytes | 1024 bytes | 32,256 bytes | 8 bytes | 16 bytes |
| UID Length | 4 bytes | 4 bytes | 7 bytes | 7 bytes | 7 bytes | 7 bytes | 7 bytes | 8 bytes | 8 bytes | 7 bytes | 7 bytes | 7 bytes | 7 bytes | 4 bytes | 7 bytes | 4 bytes | 5 bytes | 5 bytes |
| Data Protection | Crypto-1 proprietary cipher | Crypto-1 proprietary cipher | 32-bit password protection | None | 3DES & AES | AES-128/256 + ECC | AES-128 | None | None | 3DES | None | 32-bit password protection | Crypto-1 proprietary cipher | Crypto-1 proprietary cipher | Crypto-1 proprietary cipher | Proprietary key auth | None | None |
| Read/Write Cycles | 100000 | 100000 | 100000 | 100000 | 500000 | 1000000 | 200000 | 100000 | 100000 | 100000 | 100 | 100 | 100000 | 100000 | 100000 | 100000 | 0 | 0 |
| Certificate 1 | |
|---|---|
| Description | CE marking is a declaration by the manufacturer that a product meets the health, safety, and environmental standards of the European Economic Area (EEA) and can be sold freely within it. |
| Certificate 2 | |
| Standard |
ISO 9001:2015
|
| Issued By | BoA |
| Certificate Number | 65625Q7176R0Z |
| Valid Until | 20. Oct 2028 |
| Description | Third-party ISO 9001:2015 quality management system certification for the supplier, according to GB/T 19001-2016 / ISO 9001:2015. |
| Certificate 3 | |
| Standard |
AAA Credit Rating System
|
| Issued By | dun & bradstreet |
| Certificate Number | JM Band 2025 |
| Valid Until | 30. Sep 2025 |
| Description | AAA Highest Credit Worthiness Rating (2025). Issued by Dun & Bradstreet, indicating the company has an extremely strong financial position and superior ability to meet current payment obligations. This is the highest level in the credit rating scale. |
